FINECO anti-static access floors are redefining modern environments, establishing new industry standards. Built for resilience, they carry heavy equipment loads while maintaining structural stability. The innovative modular design supports rapid installation and effortless reconfiguration, reducing disruptions. A smart cable management system streamlines infrastructure organization, enhancing safety and efficiency. Static protection and fire-resistant features ensure a secure setting for vital applications, from data centers to offices and industrial zones. The corrosion-resistant finish promises long-lasting performance, while efficient airflow management increases energy conservation. FINECO delivers a reliable, elegant, and future-proof flooring solution.
Product specification
|
Model |
Concentrated Load |
Impact Load |
Ultimate Load |
Uniform Load |
Rolling Load (N) |
||
|
LB |
N |
N |
N |
N/㎡ |
10 times |
10000 times |
|
|
FS800 |
800 |
3560 |
536 |
10680 |
16100 |
3560 |
2670 |
|
FS1000 |
1000 |
4450 |
670 |
13350 |
23000 |
4450 |
3560 |
|
FS1250 |
1250 |
5560 |
780 |
16680 |
33000 |
5560 |
4450 |
|
FS1500 |
1500 |
6660 |
1005 |
19980 |
34500 |
6675 |
5340 |
|
FS2000 |
2000 |
8900 |
1340 |
26700 |
46000 |
8900 |
7120 |
* According to CE& CISCA's recommended test procedures for Access Floors
600*600mm/24'*24' (610*610mm) available
Product feature and application
FINECO's anti-static access floor panels redefine modern space solutions by blending innovative engineering with superior functionality. Crafted from premium-grade, corrosion-resistant steel and fortified with advanced fire-retardant coatings, they offer exceptional structural resilience and long-term durability. Designed to meet heavy load requirements, they provide stable support for equipment installations. The intelligent modular design streamlines deployment, enabling rapid installation and effortless adjustments to evolving spatial needs. Integrated cable conduits optimize underfloor airflow, efficiently organizing power and data lines while eliminating clutter. Perfect for critical settings-data centers, industrial facilities, command centers, and research labs-the system ensures safety, flexibility, and global compliance. Its low-maintenance design reduces operational downtime, and enhanced utility access boosts productivity. Opt for FINECO to build a foundation that addresses current needs and future-proofs infrastructure, merging robustness with elegant aesthetics for sustainable, high-performing spaces.
Product details
Advanced conductivity with static-dissipative borders defines FINECO access panels. Epoxy protection shields against harsh elements, while laminate finishes (HPL, PVC, ceramic) balance aesthetics and 10^4–10^9Ω resistance. Bolted reinforcement ensures 890kg+ load capacity, and fire cores achieve ASTM E84 Class 1. Optional gasket seals form airtight compartments, optimizing critical environments through versatile engineering.
Product Qualification
Engineered for durability, FINECO's anti-static raised floors start with elite-grade materials and sophisticated fabrication. The core is made from ST14 and SPCC steel-recognized for toughness, resistance to environmental degradation, and moldability-ensuring structural consistency in tough conditions.
Foam concrete's innovative use elevates performance, reducing mass for optimal load efficiency. It delivers great thermal and acoustic insulation plus eco-friendliness. Industrial high-pressure molding ensures uniform density and precise, defect-free geometry.
The fusion of progressive metallurgy, sustainable composite materials, and detailed manufacturing allows FINECO panels to outdo global durability norms. These panels bring lasting reliability and top performance to critical applications.
Shipping and Package
FAQ
Q: 1. How is a raised floor installed?
A: To install a raised floor, the base surface must first be evened. Pedestals with height-adjustment features are fixed in a grid pattern. Cross supports are attached, creating a stable skeleton. Floor tiles are then positioned, sealed with gaskets, and finished with edge trims for safety.
Q: 2. What are the common uses of raised floors?
A: Raised flooring is a staple in IT hubs and research facilities, enabling hidden wiring, underfloor cooling, and reconfigurable layouts, while also providing electrostatic safety and proper grounding.
Q: 3.How do I maintain a raised floor?
A: Regular checks help detect shifted tiles or weakened structural supports in raised flooring. Keep the subfloor area clean with vacuuming or sweeping. Never surpass the maximum load rating. Address damaged components quickly and manage wiring to prevent blockages and ensure easy maintenance.
Q: 4.Can raised floors be installed over existing flooring?
A: When the underlying floor is even and robust, modular raised flooring can be laid over current concrete, tile, or carpet, avoiding the need for full replacement and saving time and money.
Q: 5.Can raised flooring be disassembled and replaced by oneself?
A: Even though raised flooring can theoretically be taken apart by users, its removal and replacement demand specialists to ensure safety and operational integrity.
