The FINECO perforated panel is a full steel punched tile available with HPL or PVC surface finishes. Constructed from high‑quality SPCCID cold‑rolled hard steel supplied by Shanghai Baosteel, it features manually welded square tube reinforcements at the base using domestically sourced materials. Finished with imported coating and equipped with a conductive edge, the panel is paired with steel pressure‑formed pedestals and stringers, while its height can be precisely adjusted via the supporting lead screws for flexible installation.
Product specification
|
Model |
Concentrated Load |
Impact Load |
Ultimate Load |
Uniform Load |
Rolling Load (N) |
||
|
LB |
N |
N |
N |
N/㎡ |
10 times |
10000 times |
|
|
FS800 |
800 |
3560 |
536 |
10680 |
16100 |
3560 |
2670 |
|
FS1000 |
1000 |
4450 |
670 |
13350 |
23000 |
4450 |
3560 |
|
FS1250 |
1250 |
5560 |
780 |
16680 |
33000 |
5560 |
4450 |
|
FS1500 |
1500 |
6660 |
1005 |
19980 |
34500 |
6675 |
5340 |
|
FS2000 |
2000 |
8900 |
1340 |
26700 |
46000 |
8900 |
7120 |
* According to CE& CISCA's recommended test procedures for Access Floors
600*600mm/24'*24' (610*610mm) available
Product feature and application
The FINECO perforated panel demonstrates outstanding adaptability for a wide spectrum of professional environments that demand reliable antistatic performance and efficient air conditioning management. It is highly suitable for computer rooms, network server rooms, centralized monitoring and control centers, electronic production workshops, clean rooms, safety equipment rooms, and various other precision-sensitive sites. With its stable structure and well-designed airflow distribution, the panel effectively meets the strict requirements of modern intelligent facilities, ensuring safe and stable operation of electronic equipment. Whether in data centers, industrial workshops, or critical control areas, it provides reliable antistatic protection and efficient cooling ventilation, making it an ideal solution for infrastructure construction in high-standard technical sites.
Product details
The FINECO perforated panel features an antistatic top surface, antistatic PVC edging on all four sides, and a galvanized steel base plate. It offers a ventilation rate from 16% to 65% and is constructed from steel or aluminum with an epoxy coating. Boasting high dimensional accuracy and strong load-bearing capacity, it performs stably under varying temperature and humidity. The panel is non-combustible with Class A fire resistance, and its directional airflow grille ensures efficient cooling. Highly flexible and reusable, it is ideal for data centers and modern industrial environments.
Product Qualification
Produced with strict quality control systems, FINECO raised floor solutions apply high-grade raw materials and modern manufacturing processes. Constructed with ST14 and SPCC steel materials, these floor systems deliver outstanding structural strength, reliable anti-corrosion performance, and superior formability. They maintain consistent stability and long-term durability even under heavy‑use and challenging industrial environments, ensuring safe and stable operation for various critical applications.
The use of high-quality steel effectively reduces product weight while significantly enhancing overall performance, achieving superior load-bearing efficiency. This material delivers outstanding performance in heat insulation, sound absorption, and environmental protection. Industrial-grade high-pressure forming technology is adopted to ensure uniform density and flawless structural dimensional accuracy.
By integrating cutting-edge metallurgical technology, eco-friendly composite materials, and precision manufacturing processes, FINECO panels achieve exceptional product quality that fully exceeds international industry standards in terms of structural durability and service life. Every panel is engineered to maintain long-term dimensional stability, reliable mechanical performance, and consistent functionality even under long-term, high-intensity use. Designed specifically for mission-critical infrastructure and key core facilities, they provide stable, safe, and high-efficiency operational support, effectively reducing maintenance costs while ensuring continuous and reliable operation of vital equipment and systems.
Shipping and Package
FAQ
Q: 1. What is a raised floor system?
A: By elevating floor panels on support posts, a raised floor system generates a concealed area perfect for running power, data, and HVAC lines without disrupting the usable space above.
Q: 2. How is a raised floor installed?
A: Prior to installation, the substrate must be flat. Pedestals are fixed at designated points and leveled. Stringers are added to form a rigid framework. Panels are placed, adjusted, sealed with gaskets, and edged with safety profiles.
Q: 3.How do I maintain a raised floor?
A: Proper upkeep of a raised floor includes periodic checks for loose tiles or damaged supports. Remove dirt from beneath using vacuum systems. Avoid surpassing weight limits. Replace damaged parts promptly and manage cables to prevent blockages.
Q: 4.Can raised floors be adjusted after installation?
A: Even after being installed, raised floors remain dynamic. Height-modifiable pedestals and modular tiles support continuous infrastructure updates.
Q: 5.What issues might I encounter with raised floors?
A: Raised floor systems risk deformation under constant heavy loads, experience reduced airflow from packed cables, and may develop safety hazards from loose components-addressed through regular maintenance.
